170M7595 Fuse Datasheet
Square Body Flush End Contact Size 4 — 1250V (IEC):1400-2500A
1250V (IEC) 1400-2500A
Fuse Specifications
Description: High speed square body fuses, for the protection of the power rectifier section of the equipment.
Fuse Ratings:
Volts: — 1250Vac (IEC)
Amps: — 1400-2500A
IR: — 125kA RMS Sym
| Fuse Size | Catalog Number | Electrical Characteristics | |||||
| -BKN/105 TypeK Indicator | -SBKN/105 TypeK Indicator | Rated Voltage (V) | Rated Current RMS-Amp | ft (A2Sec) | Watt Loss (W) | ||
| Pre-arc | Clearing at 1250V | ||||||
| 170M7217 | 170M7512 | 1400 | 800000 | 5000000 | 195 | ||
| 170M7597 | 170M7510 | 1500 | 1000000 | 6200000 | 200 | ||
| 170M7676 | 170M7511 | 1700 | 1400000 | 8700000 | 220 | ||
| 4 | 170M7532 | 170M7976 | 1250 | 1800 | 1700000 | 11000000 | 225 |
| 170M7633 | 170M7513 | 2000 | 2300000 | 14500000 | 235 | ||
| 170M7592 | 170M7546 | 2200 | 3100000 | 19500000 | 245 | ||
| 170M7107 | 170M7516 | 2400 | 4000000 | 25000000 | 255 | ||
| 170M7595 | 170M7978 | 2500 | 4500000 | 28000000 | 260 | ||
Fuse Size
