- Specification
- Datasheet download
Specifications:
• Volts - 1000 Vdc
• Amps – 600 A
• Interrupting rating Max DC 25 kA as baseline Min <=200a, dc="">200A, 200%, DC
• Time constant - 3ms
• Ambient temperature -40 ~ 125 degree centigrade
• Altitude: <=2000 meter
| Size | Current Rating (A) | A | B | c | D | E | F | G | H |
| EVK25 | 70 ~ 120 | 72.2 | 93.0 | 110.0 | 25.4 | 9.0 | 11.0 | 19.0 | 2.2 |
| EVK30 | 125~200 | 72.2 | 93.0 | 110.0 | 31.0 | 9.0 | 11.0 | 25.0 | 3.0 |
| EVK40 | 225~ 300 | 72.2 | 100.0 | 122.0 | 38.1 | 11.0 | 13.0 | 28.0 | 3.5 |
| EVK50 | 350~ 400 | 72.2 | 100.0 | 122.0 | 50.8 | 11.0 | 13.0 | 28.0 | 5.0 |
| EVK60 | 450 ~ 600 | 72.2 | 100.0 | 122.0 | 63.5 | 11.0 | 13.0 | 40.0 | 6.0 |
