Bussmann DC fuses provide the ultimate protection of the electric vehicle. such as: battery modules and battery packs. Bussmann DC fuses have been tested to provide DC applications best-in-class performance.
Such as: EV30-400.500VDC, 400amp fast acting fuse
- Specification
- Datasheet download
| Product Name | Eaton Bussmann series high speed cylindrical fuse |
| Catolog Number | FWH-90B |
| Rated Amperage | 90A |
| Rated Voltage | 500V |
| Datasheet | |
| Product Length | 108mm |
| Product Height | 28mm |
| Product Width | 90mm |
| Product Weight | 63.8g |
| Class | Class aR |
| Product Type | High speed fuse |
| Voltage Type | DC/AC |
| Package Type | Standard |
| Breaking Capacity | • 200 kA RMS Sym. • 50 kA at 500 Vdc |
| Fuse Holder | BH-0112 |
| Application | Semiconductor, DC Common bus, DC drives, Power converters/rectifiers |
| Certification | • UL Recognized, JFHR2, E91958, FWH-_B (35-200 A) and FWH-_A (1000 and 1200 A), JFHR2, E56412 FWH-_A (225-800 A) • CSA Class 1422-30, File 53787 (35-1600 A) • CE |
