HPS Imperator™
Encapsulated Industrial Control Transformers
INNOVATIVE DESIGN
The HPS Imperator’s unique terminal block design allows
for the quick and easy installation of standard secondary or
optional primary 13/32” x 1 1/2” midget/type CC fuse clips
on every unit. This is the simplest and most inexpensive
fusing installation provided on any industrial control
transformer in the market today.
THE PERFECT SOLUTION
With 11 standard voltage groups, a VA range from 50VA
to 1500VA and available with standard secondary and
optional primary fuse kits, the HPS Imperator series
provides the perfect solution for any application.
SUPERIOR QUALITY & VALUE
The HPS Imperator series design, utilizing superior insulation
systems and being constructed with high quality silicon steel
laminations for optimum performance, meet or exceed UL,
CSA and CE standards.
APPLICATIONS
| INDUSTRIES
|
APPROVALS
•UL Listed (Approved for U.S. and Canada)
•CE Mark standard on all units
•RoHS Compliant
FEATURES AND BENEFITS
•600V class, rated industrial control transformers
•11 standard multi primary and secondary voltage groups available1
•50/60 Hertz (60Hz on PH***AJ & PH***AR)
•VA range from 50 up to 15001
•Robust insulation system:
• 50-150VA, temperature rise 55°C, insulation class 130°C
• 250-1500VA, temperature rise 80°C, insulation class 130°C
•Constructed with high quality silicon steel laminations that provide optimum performance and reliability
•Encapsulated coils encased in a custom injection molded cover, protect coils and terminations from moisture,
dirt and other industrial airborne contaminants
•Mounting Feet: made of heavy steel and welded or bolted to the core, these mounting feet provide superior
strength in a compact design
•Termination: combination slot/Phillips #6 screw, complete with SEMS washer (suitable for 18 AWG to 14 AWG
solid or 14 AWG stranded wire)
•Standard SEMS washers - supplied on all units2
•Standard secondary fuse kits -utilizing 13/32” x 1 1/2” midget/type CC fuse clips (supplied with all units)
•Optional primary fuse kits available utilizing 13/32” x 1 1/2” midget/type CC fuse clips
•Optional finger safe terminal covers available on all units
•LIFETIME Warranty (Limited)
1 special voltages and VA sizes available upon request
2 excluding PH750PG, PH1000PG, PH750MLI, PH1000MLI
Primary Voltage: 480/240 Secondary Voltage: 120/25 | 460/230/208
115/24 |
440/220/200
110/23
| 50/60 Hertz |
|
| VA Rating | Catalog Number | Mtg. Fig. | Output Amps | Overall Dimensions | Mounting Centers | Mounting Slot | Height with Finger Guard | Depth with Finger Guard | Approx. Ship Weight Lbs. | Optional Primary Fuse Kit P/N |
| A | B | C | D | E | GXH |
| 50 | PH50MLI | A | 0.43/2.08 | 3.25 | 4.06 | 3.56 | 2.63 | 2.50 | 0.22 x 0.44 | 4.37 | 5.50 | 4.00 | PFK5 |
| 75 | PH75MLI | A | 0.65/3.13 | 3.25 | 4.25 | 3.56 | 2.63 | 2.50 | 0.22 x 0.44 | 4.37 | 5.69 | 4.60 | PFK5 |
| 100 | PH100MU | A | 0.87/4.17 | 3.25 | 4.69 | 3.63 | 2.63 | 2.63 | 0.22 x 0.44 | 4.50 | 6.25 | 5.20 | PFK5 |
| 150 | PH150MU | B | 1.30/6.25 | 4.00 | 5.44 | 3.81 | 3.38 | 2.75 | 0.22 x 0.75 | 4.50 | 6.94 | 7.60 | PFK6 |
| 250 | PH250MU | B | 2.17/10.42 | 4.50 | 5.19 | 4.44 | 3.75 | 3.75 | 0.22 x 0.75 | 5.18 | 6.69 | 10.1 | PFK6 |
| 350 | PH350MU | B | 3.04/14.58 | 4.50 | 5.56 | 4.44 | 3.75 | 3.75 | 0.22 x 0.75 | 5.18 | 7.06 | 11.0 | PFK7 |
| 500 | PH500MU | B | 4.35/20.83 | 4.75 | 6.69 | 4.31 | 4.06 | 4.50 | 0.31x0.94 | 5.13 | 8.19 | 163 | PFK7 |
| 750 | PH750MU | C | 6.52/31.25 | 5.25 | 6.50 | 4.94 | 4.50 | 4.13 | 0.31x0.81 | 5.56 | 8.31 | 21.0 | PFK7 |
| 1000 | PH1000MLI | C | 8.70/41.67 | 5.25 | 8.19 | 4.94 | 4.50 | 5.81 | 0.31x0.81 | 5.56 | 9.69 | 31.2 | PFK7 |
Secondary fuse clips and fuse clip mounting screws supplied standard with transformers up to and including
500VA. Primary and secondary voltage links/jumpers
supplied standard with transformers. Please refer to page 11 for dimensional drawings. Special voltages and
VA sizes available upon request.All dimensions in inches
