XTCE032C10A
Eaton XT IEC contactor, 32A, 110 Vac 50 Hz, 120 Vac 60 Hz, 1NO,
32A, Frame C, 45 mm, 50-60 Hz, 3, 5, 5/ 10, 10, 20, 25 hp
(1/3PH @115, 200, 230/200, 230, 460, 575 V), Three-pole, , Screw terminals, FVNR
| PRODUCT NAME | Eaton XT IEC contactor |
| CATALOG NUMBER | XTCEO32C10A |
| EAN | 4015082772574 |
| PRODUCT LENGTH/DEPTH | 4 in |
| PRODUCT HEIGHT | 2 in |
| PRODUCT WIDTH | 3.5 in |
| PRODUCT WEIGHT | 1 Ib |
| COMPLIANCES | CE Marked |
| RoHS Compliant | |
| CERTIFICATIONS | UL Listed |
| CSA Certified | |
| IEC 60947 | |
| EN 60947 | |
| CATALOG NOTES | Screw terminals (6-65A); 5 mm (80-150A); no lugs (185-2000A) |
| PRODUCT SPECIFICATIONS | |
| FRAME SIZE | 45 mm |
| CONTACT CONFIGURATION | 1 NO |
| COIL VOLTAGE | 110-120 Vac, 50/60 Hz |
| SERIES | XT IEC |
| TYPE | Full voltage non-reversing contactor |
| HP RATING -MAX | 3, 5,5/ 10,10,20,25 hp(1/3PH @115,200,230/200,230,460,575 |
| V) | |
| CONTINUOUS AMPERE RATING | 32A |
| FREQUENCY RATING | 50-60 Hz |
| TERMINALS | Screw terminals |
| OPERATION | Non-reversing |
| AMPERAGE RATING | 32A |
| NUMBER OF POLES | Three-pole |
