BG100B12UX3-I BYD IGBT Power Module

BG100B12UX3-I BYD IGBT Power Module

BYD IGBT Power Module BG100B12UX3-I provides fast switching characteristic as well as high short circuit capability, which introduce the advanced IGBT chip/FWDand improved connection.

Features

 High speed IGBT technology

 Including ultra fast & soft recovery anti-parallel FWD

 Low inductance

 Standard package

 High short circuit capability

 Fast switching and short tail current

Applications

 High frequency drivers

 AC motor control

 Inverters

 Servo

 UPS (Uninterruptible Power Supplies)

 Electric welding

BG100B12UX3-I Circuit Diagram
