FWP-40A22F Bussmann High Speed Fuse
| Product name | Eaton Bussmann series high speed cylindrical fuse |
| Part no. | FWP-40A22F |
| Voltage Rating | 700VDC, 700VAC |
| Current Rating | 30A |
| Datasheet | |
| Product Length | 58mm |
| Product height | 23mm |
| Product width | 23mm |
| Product weight | 60g |
| Standard/Approval | UL Recognized CSA Certified |
| Material | Ceramic |
| Class | Class aR |
| Used with | Finger safe holders/blocks and striker |
| CAD,3D Model | stp |
FWP-xx22F Fuse Dimensions -mm, without Striker
