JKS-350 | Class J Fuse | Bussmann Fuse
| Product Name | Eaton Bussmann Class J Fuse |
| Brand | Cooper Bussmann |
| Fuse Type | Dual Element Fast Acting Fuse |
| Catolog Number | JKS-350 |
| Rated Amperage | 350A |
| Rated Voltage | 600VAC |
| Datasheet | |
| Product Length | 7.13 in |
| Product Diameter | 2 in |
| Product Weight | 2 lb |
| Class | Class J |
| Voltage Type | AC |
| Alternate | A4J350 |
| Connection | Bolted blade end x bolted blade end |
| SPQ | 1 |
| Breaking Capacity | 200 kA |
| 3D Model; CAD | Contact us |
| Typical applications | • Power panelboards • Machinery disconnects |
| Agency Information | 600 Vac, UL Listed, Std. 248-8, Class J, Guide JDDZ, File E4273, CSA Certified, Class 1422-02, File 53787, CE |
