LPJ-150SP
Eaton Bussmann series LPJ fuse, Low-peak fuse, 150 A, Dual, Class J,
With indicator, Bolted blade end x bolted blade end, Time delay|Current-limiting,
10 sec at 500%, 100 kAIC Vdc|300 kAIC at 600 V, Standard
| GENERAL SPECIFICATIONS | |
| PRODUCT NAME | Eaton Bussmann series LPJ fuse |
| CATALOG NUMBER | LPJ-150SP| |
| UPC | 051712627993 |
| PRODUCT LENGTH/DEPTH | 2.25 in |
| PRODUCT HEIGHT | 0.81 in |
| PRODUCT WIDTH | 0.81 in |
| PRODUCT WEIGHT | 0.73 lb |
| WARRANTY | Not Applicable |
| COMPLIANCES | CE Marked |
| RoHS Compliant |
Bussmann lpj 150sp
Bussmann Fuse, Semiconductor Fuse, Time Delay Fuse, High Speed Fuse, Class J Fuse, Class T Fuse, Class cc fuse, Class RK1 Fuse, Class RK5 Fuse, Class L Fuse, DC Contactor, Disconnect Switch, Car Fuse, Current Limiting Fuse, HV Fuse, Bussmann Fuse Holder, AC Fuse, DC Fuse
You can ask any Bussmann fuse and fuse cross reference(Littelfuse, Mersen, etc).
